Drip Coffee Packaging Machine

C19H-2 Ultrasonic Drip Coffee Bag Packing Machine

We Promise:
1.Testing machine for free
2.Training for free
3.One year for warranty
4.Onsite service
Support Hotline:+8613779964655

Product Description

C19H-2 Automatic Ultrasonic Drip Coffee Bag Packing Machine

Type: Drip Coffee Packing Machine Series

Product model: C19H-2

Product name: Ultrasonic Drip Coffee Inner and Outer Bag Packing Machine

Outer bag with four sides sealing round edge with V type tear

Purpose: Outer bag sealing controlled by the servo motor, bag length positioning is accurate and stable.

Feature: Outer bag sealing controlled by the servo motor , bag length positioning isaccurate and stable.

Adopts PID temperature controller for more accurate temperature adjustment.Adopts PLC control system, human-machine interface, it is very easy to operate.

All parts in direct contact with products are made of suS304 stainless steel,ensuring reliable products output conforming to food sanitary standards.Some parts of the cylinder are imported, ensuring the accuracy and stabilityof performance.

Optional devices: flat cut device, date printer, easy tear device,etc.

Packing Material: Paper/Plastic, Plastic/Aluminum/Plastic, PaperlAluminum/Plastic, Drip coffee filter paper


Bag type: 3 side sealing

Outer Bag size: L:85~120mm,W:75~100mm (Film width200mm, Bag size: 120*100mm)

lnner Bag size: L:50~75mm, W:50~90mm (Filter paperwidth 180mm, Bag size: 90*74mm)

Packing speed: 50~70 bag/min

Filling range: 5~15 g

Power: Single phase,220V,50HZ,3.7KW

Air supply: ≥0.6Mpa(optional with air compressor)

Weight: 850KG

Dimension(L*W*H): L1600mm*w900mm*H2600mm
