C89K Automatic drip coffee bag packing machine (bag type)

C89K AUTOMATIC DRIP COFFEE BAG PACKING MACHINE (BAG TYPE)

Type: Automatic drip coffee bag packing machine(bag type)

Product model: C89K

Product name: Ultrasonic Drip Coffee Inner and Outer Bag Packing Machine Outer bag with four sides sealing round edge with V type tear

Purpose: lt is suitable for inner and outer bag packaging for tea leaves, herbal tea,health care tea, coffee, roots, and other small granule products.

Feature: The inner bag and outer bag of this machine are automatically ompletedby one same machine, which is safe, hygienic and space-saving.

Adopts PID temperature controller for more accurate temperature

adjustment. adopts PLC control system, human-machine interface, it isvery easy to operate.All parts in direct contact with products are madeof sus304 stainless steel, ensuring reliable products output conformingto food sanitary standaards.Some parts of the cylinder are imported,ensuring the accruacy and stability of performance.

Additional function online printing date etc.

Packing Material: Paper/Plastic, Plastic/Aluminum/Plastic, PaperlAluminum/Plastic, Drip coffee filter paper, kraft paper

Bag type: 4 side seal premade bag

Outer Bag size: L:120~130mm, W:100~110mm

L:50~75mm, W:50~90mm (Filter paper

lnner Bag size: width 180mm, Bag size: 90*74mm)

Packing speed: 25~35 bags/min

Filling range: 5~15g accuracy士0.1g/bag

Power: Single phase, 220V,50HZ,5.5KW

Pressure: ≥0.6Mpa(optional with air compressor)

weight: 800KG

Dimension: L1700mm*W900mm*H2500mm
