C18-2 Automatic Multi-function Tea Bag Packing Machine

C18-2 Automatic Multi-function Tea Bag Packing Machine (Optional with Outer Envelope, Thread and Tag)
 （Indirect）

Type: Tea Bag Packing Machine Series

Product model: C18-2

Product name: Automatic Inner and Outer Tea Bag Packing Machine With Thread And Tag (Indirect)lt is suitable for double bag packing of small granular products,such as tea

Purpose: leafs, medicinal tea and health care tea.

The inner and outer bag forming is finished at same time , avoid human handsdirect contact with the packing material and improve working efficiency.

Inner bag is made of filter paper which can be automatically threaded andlabeled .

Feature: The outer bag is made of composite film which biggest advantage is outer bagcan be positioned by photo electricity.

The packing capacity, inner bag, outer bag, and tag can be easy adjust.Theinner bag and outer bag size can be adjusted according to the different

requirements in order to the best packing effect, improve product appearanceand increase the value of the product.

Packing Material: Paper/Plastic,Plastic/Plastic,Plastic/Aluminum/Plastic,PaperlAluminum/Plastic,Tea filter paper，Thread,Tag paper.

Measuring: Volumetric cup filler

Filling range: 3~15ml

Packing speed: 40~50 bags/min

Tag Size: L:20~24mm , W:40~55mm

Thread Length: 155mm

lnner Bag size: L:50~70mm , W:40~80mm

Outer Bag size: L:70~120mm , W:75~90mm

Power: 220V,50HZ,3.7KW

Air supply: ≥0.6Mpa(optional with air compressor)

Weight: 500KG

Dimension: 1250*700*1800mm(L*W*H)
