C20DX-BK Full Automatic Pyramid Nylon Tea Bag Packing Machine

C20DX-BK Automatic Pyramid Tea Bag Packing Machine (with Vacuum Outer Envelope)

Application:
It is suitable for packing kinds of tea in pyramid bag with vacuum sealed outer envelop, such as Darjeeling tea, Assam tea, Ceylon tea, Kung Fu tea, rose tea, jasmine tea, oolong tea, Pu’er tea, health tea, herbal tea etc.

Features:
1. The feasible package materials of the triangle bag machine is nylon, PLA, non-woven fabric materials imported from Japan, which is non-toxic, non-bacteria, heat-resistant, high-quality and food-grade, conforming to our national safety inspection standard.
2. The machine can uses a unique sealing method - ultrasonic. It can seal tightly, safely, and reduce the width of the extra edge, avoiding any waste of packing materials.
3. Adopting the bag vacuum packaging to makes its appearance more good-looking and keeps it fresh to a higher quality.

Technical data:
Machine type: Tea Bag Packing Machine Series
Machine model: C20DX-BK
Machine name: Automatic Pyramid Tea Bag Packing Machine  (With Vacuum Outer Envelope)
Packing material: Nylon material imported from Japan, non-woven fabric, 100%

biodegradable transparent materials, PET, PLA, Aluminum composite film etc
Measuring method: Electric scale filling
Filling range: 1-10g/bag, accuracy: ≤ ±0.2g/bag
Packing speed: 20~30 bags/min
Packing roll width: 120, 140, 160(mm)
Sealing length: 50, 60, 70, 80(mm)
Sealing method : Sealing and cutting by ultrasonic
Qty of sealing device: 2 sets
 Air supply: ≥0.6MPa(can be equipped with air compressor)
Motor power: 220V, 50HZ, 3.7KW
Dimension: 6000*2000*2300mm(L*W*H)
Machine weight: 750KG
